Description
Technical Parameters
Size: length*width*height 6*15*5 (mm), the size can be customized according to customer needs.
Material: stainless steel 304, stainless steel 420, stainless steel 440, stainless steel 316, the material can be customized according to customer needs.
Neutral salt spray certification for 260 hours.
Ball bearing salt spray certification test is tested in accordance with ISO 9227 standards

|
68 |
Shield |
2 |
304/201/301+NBR |
|
07 |
retainer |
2 |
PA66+GF25 |
|
04 |
Ball S 5.556 |
2X7 |
AISI 440 |
|
02 |
Inner ring |
1 |
AISI 440 |
|
01 |
Outer ring |
1 |
AISI 440 |
According to whether it can be aligned during work, it can be divided into self-aligning bearings-the raceway is spherical, which can adapt to the angular deviation and angular motion between the two raceway axes and the non-aligning bearing (rigid bearing) ---- Bearings that can resist the offset of the axis line angle between the raceways.
Hot Tags: s696 bearing, China s696 bearing manufacturers, suppliers, factory, stainless steel rod end, one inch steel ball, S608 Bearing, stainless steel ball bearings, S604 Bearing, S6904 Bearing
