S697 Bearing
Description
Technical Parameters
Size: length*width*height 7*17*5 (mm), the size can be customized according to customer needs.
Material: stainless steel 304, stainless steel 420, stainless steel 440, stainless steel 316, the material can be customized according to customer needs.
According to the number of rows of rolling elements, it is divided into single-row bearings, double-row bearings and multi-row bearings.
Neutral salt spray certification for 260 hours.
Ball bearing salt spray certification test is tested in accordance with ISO 9227 standards

|
68 |
Shield |
2 |
304/201/301+NBR |
|
07 |
retainer |
2 |
PA66+GF25 |
|
04 |
Ball S 5.556 |
2X7 |
AISI 440 |
|
02 |
Inner ring |
1 |
AISI 440 |
|
01 |
Outer ring |
1 |
AISI 440 |
