S603 Bearing

Size: length*width*height 3*9*3 (mm), the size can be customized according to customer needs.
Send Inquiry

Description

Technical Parameters

Size: length*width*height 3*9*3 (mm), the size can be customized according to customer needs.

Material: stainless steel 304, stainless steel 420, stainless steel 440, stainless steel 316, the material can be customized according to customer needs.



Neutral salt spray certification for 260 hours.

Ball bearing salt spray certification test is tested in accordance with ISO 9227 standards



68

Shield

2

304/201/301+NBR

07

retainer

2

PA66+GF25

04

Ball S 5.556

2X7

AISI 440

02

Inner ring

1

AISI 440

01

Outer ring

1

AISI 440



Uses for Fishing gear, medical equipment, brushless motors, fan motors, precision instruments
