Description
Technical Parameters
Uses for medical equipment, brushless motors, fan motors, precision instruments, gearboxes, household appliances, internal combustion engines, transportation vehicles, agricultural machinery, construction machinery, roller skates, office equipment, currency counters, mechanical equipment, fitness equipment , bladeless fan motor bearings, remote control cars
Neutral salt spray certification for 260 hours.
Ball bearing salt spray certification test is tested in accordance with ISO 9227 standards

|
68 |
Shield |
2 |
304/201/301+NBR |
|
07 |
retainer |
2 |
PA66+GF25 |
|
04 |
Ball S 5.556 |
2X7 |
AISI 440 |
|
02 |
Inner ring |
1 |
AISI 440 |
|
01 |
Outer ring |
1 |
AISI 440 |
Size: length*width*height 20*42*12 (mm), the size can be customized according to customer needs.
Material: stainless steel 304, stainless steel 420, stainless steel 440, stainless steel 316, the material can be customized according to customer needs.
